Tarp Gear Motor w/Chrome Cover Dump Truck Tarp Motor / Canvas Engine ( Tipper Sheeting Motor, Dura-Torque Gearmotor ), fits most automatic tarps systems.600W TARP MOTOR 80ZYT-12/JW-7 SPECS AND FEATURE (GEAR RATIO 90:1):3 years warrantyHi-torque, direct drive 12VDC (or 24VDC) motor (output torque 600 in-lbs)90:1 gear ratio.No-load Speed 55RPM / Rated Speed 40 RPM (+/-5RPM)Power 600W (Motor body Length 116mm) or 900W (Motor body Length 141mm, Model 80ZYTS-12/JW-7 )Epoxy sealed gearbox maintains lubrication.2-1/2" x 3/4" extended output shaft fits wide range of tarp systems.Sealed drive shaft and encased bearing prevents contamination.Chrome/plastic cover and fasteners included.Waterproof Level IP65100% tested for quality control.Optional 24V DC, Gear Ratio 60:1 or 45:1, 900W/1.2HP, 1200W/1.5HP, 2.0HP, 2.5HPAmbient temperature of minus 40° available upon requestReplaces Aero Power Plus, Donovan 1704878, 1800716, 1801965*, 1802061, 1802066, Roll-Rite #1030/1031, US Tarp #13732, 13957, 15275, 15938, 15364, 13655; Pulltarps 517-0906/517-0909; SHUR-CO 1703823; SuperWinch 90-33319/90-33295; Tarps and Beyond 1000XT/2000XT; Buyers Products 5543965/5541065, TSI Apache, Tomahawk, Enforcer.

Tarp Gear Motor w/Chrome Cover Dump Truck Tarp Motor / Canvas Engine ( Tipper Sheeting Motor, Dura-Torque Gearmotor ), fits most automatic tarps systems.900W TARP MOTOR 80ZYT-12/JW-7 SPECS AND FEATURE (GEAR RATIO 90:1):3 years warrantyHi-torque, direct drive 12VDC (or 24VDC) motor (output torque 800 in-lbs)90:1 gear ratio.No-load Speed 55RPM / Rated Speed 40 RPM (+/-5RPM)Power 600W (Motor body Length 116mm) or 900W (Motor body Length 141mm, Model 80ZYTS-12/JW-7 )Epoxy sealed gearbox maintains lubrication.2-1/2" x 3/4" extended output shaft fits wide range of tarp systems.Sealed drive shaft and encased bearing prevents contamination.Chrome/plastic cover and fasteners included.Waterproof Level IP65100% tested for quality control.Ambient temperature of minus 40° available upon requestOptional 24V DC, Gear Ratio 60:1 or 45:1, 600W/0.8HP, 1200W/1.5HP, 2.0HP, 2.5HPReplaces Aero Power Plus, Donovan 1704878, 1800716, 1801965*, 1802061, 1802066, Roll-Rite #1030/1031, US Tarp #13732, 13957, 15275, 15938, 15364, 13655; Pulltarps 517-0906/517-0909; SHUR-CO 1703823; SuperWinch 90-33319/90-33295; Tarps and Beyond 1000XT/2000XT; Buyers Products 5543965/5541065, TSI Apache, Tomahawk, Enforcer.

IP67 FUEL PUMP MOTOR GENERAL SPECS.  DC 24V  No-Load Speed 5000RPM  Rated Output Speed 3500RPM   Rated Output Power 300W   Insulation Class B   IP67 or IP69K  Customized shaft & front cover available upon request

General Technical Specifications: Motor Type: Brushless / Brushed DC gear motor Operating Voltage: 12 ~ 24V DC Rated Speed: 20 ~ 70rpm Rated Torque: 1.0N.m ~ 5.0N.m Life time: 2000 ~ 5000 hours Typical Motor Type: 36mm; 42mm diameter long life brushless DC planetary gear motors; 36mm; 42mm diameter brushed DC planetary gear motorsOptional magnetic encoder

Replacement Motor for Lippert LC141893 / LC196308 / M-9000-PK Trailer Landing Gear Motor Heavy Duty DriveReplacement Motor for Stromberg Carlson Electric Landing Gear - 6,500 lbsItem # LC141893 / LC196308 / M-9000-PK12V DC GEARMOTORNo-load Current 3.5ANo-load Speed 200rpmMax. Efficiency Point DataCurrent 18ASpeed 180rpmTorque 7N.mMax. Efficiency 61%Working Point DataCurrent 35ASpeed 158rpmTorque 15N.mGEAR RATIO 35.8:1With Current Limiting Protector ( 40Amps )UL, CE, Reach and RoHS approvalOptional components: magnetic/optical encoder; brake; connectorCustomized shaft dimensions and technical specifications are available upon requestedTypical Applications: High-Speed Power Stabilizer Jack, RV Leveling System, Trailer Leveling System, Trailer Electric Landing Gear

136373  RV Slide Out Motor 28:1 Ratio 8532-08JModel: 63ZY116-1257/160JB28GItem # 136373, 8532-08JVoltage 12V DCNo-load Current 2.5ANo-load Speed 5800rpmMax. Efficiency Point Data:Current 20ASpeed 160rpmTorque 8.0N.mMax. Efficiency 60%Gear Ratio 28 : 1Max. Current 30AWith Current Limiting ProtectorUL, CE, Reach and RoHS approvalOptional components: magnetic/optical encoder; brake; connectorCustomized shaft dimensions and technical specifications are available upon requestedTypical Applications: High-Speed Power Stabilizer Jack, RV Leveling System, Trailer Leveling System

DYD PLANETARY GEARHEAD ( OD mm ): 16mm, 22mm, 24mm, 28mm, 30mm, 32mm, 36mm, 40mm, 42mm, 45mm, 48mm, 52mm, 56mm,  60mm, 72mm, 80mm, 82mm,  92mm, 110JX, 120JXDYD MOTOR TYPES: Brushed DC Motor, Brushless DC Motor, Stepping Motor, AC Motor.Multiple Ratios available Low noise levelSmooth and Quiet Operation for Continuous UseHigh Rated Torque up to 1000N.mCustomized Shaft Material and Shaft Dimensions Available.Extremely High Efficiency with Only 8% Loss Per Train!

APPLICATIONS: ·  Automatic Sliding Gate, Sliding Gate Operator, Gate Opener.MOTOR SPECS & FEATURE·  Motor OD Size: ·  Voltage: 12V DC, 24V DC, 36V DC, 48V DC·  Power: 80W, 100W, 110W, 120W, 150W·  Output Speed: 1500rpm / 1800rpm / 2500rpm / 2800rpm / 3000rpm / 3600rpm·  Without Gearbox·  Customized shaft & front cover available upon request
