Motor typeBrush commutated DC motor Gearbox typeSpurSizeGearbox: 80mm; DC motor:71mmNominal voltage12V/24V DC or customizedGear ratio 1:3 ~1:150No load current0.40A; 0.50ANo load speed2000rpm; 3000rpmNominal current2.40A; 3.50ANominal speed1600rpm; 2400rpmPermissible load rangeup to 10.0N.m for S1 duty cycleNominal power33.0W; 59.0WIP ratingup to IP68

Motor typeBrush commutated DC motor Gearbox typeSpurSizeGearbox: 80mm; DC motor:80mmNominal voltage12V/24V DC or customizedGear ratio 1:3 ~1:150No load current0.40A; 0.50ANo load speed2000rpm; 3000rpmNominal current1.2A; 2.0ANominal speed1700rpm; 2600rpmPermissible load rangeup to 10.0N.m for S1 duty cycleNominal power18.0W; 33.0WIP ratingup to IP68

Motor typeBrush commutated DC motor Gearbox typeSpurSizeGearbox: 80mm; DC motor:80mmNominal voltage12V/24V DC or customizedGear ratio 1:3 ~1:150No load current0.40A; 0.50ANo load speed2000rpm; 3000rpmNominal current3.0A; 5.0ANominal speed1700rpm; 2600rpmPermissible load rangeup to 10.0N.m for S1 duty cycleNominal power45.0W; 80.0WIP ratingup to IP68

Motor typeBrush commutated DC motor Gearbox typeSpurSizeGearbox: 80mm; DC motor:80mmNominal voltage12V/24V DC or customizedGear ratio 1:3 ~1:150No load current0.30A; 0.50ANo load speed2000rpm; 3000rpmNominal current3.5A; 7.50ANominal speed1700rpm; 2600rpmPermissible load rangeup to 10.0N.m for S1 duty cycleNominal power57.0W; 120.0WIP ratingup to IP68

Motor typeBrush commutated DC motor Gearbox typeSpurSizeGearbox: 90mm; DC motor:80mmNominal voltage12V/24V DC or customizedGear ratio 1:3 ~1:150No load current0.40A; 0.50ANo load speed2000rpm; 3000rpmNominal current3.0A; 5.0ANominal speed1700rpm; 2600rpmPermissible load rangeup to 20.0N.m for S1 duty cycleNominal power45.0W; 80.0WIP ratingup to IP68

Motor typeBrush commutated DC motor Gearbox typeSpurSizeGearbox: 90mm; DC motor:80mmNominal voltage12V/24V DC or customizedGear ratio 1:3 ~1:150No load current0.30A; 0.50ANo load speed2000rpm; 3000rpmNominal current3.5A; 7.50ANominal speed1700rpm; 2600rpmPermissible load rangeup to 20.0N.m for S1 duty cycleNominal power57.0W; 120.0WIP ratingup to IP68

Motor typeBrush commutated DC motor Gearbox typeSpurSizeGearbox: 90mm; DC motor:80mmNominal voltage12V/24V DC or customizedGear ratio 1:3 ~1:150No load current1.50A; 0.30ANo load speed3000rpm; 1700rpmNominal current12.0A; 3.0ANominal speed3000rpm; 1700rpmPermissible load rangeup to 20.0N.m for S1 duty cycleNominal power114.0W; 57.0WIP ratingup to IP68

Motor typeBrush commutated DC motor Gearbox typeSpurSizeGearbox: 90mm; DC motor:83mmNominal voltage12V/24V DC or customizedGear ratio 1:3 ~1:150No load current0.80A; 0.90ANo load speed2000rpm; 3000rpmNominal current3.50A; 4.60ANominal speed1700rpm; 2500rpmPermissible load rangeup to 20.0N.m for S1 duty cycleNominal power42.0W; 77.0WIP ratingup to IP68

Motor typeBrush commutated DC motor Gearbox typeSpurSizeGearbox: 104mm; DC motor:80mmNominal voltage12V/24V DC or customizedGear ratio 1:3 ~1:150No load current0.30A; 0.50ANo load speed2000rpm; 3000rpmNominal current3.50A; 7.50ANominal speed1700rpm; 2600rpmPermissible load rangeup to 30.0N.m for S1 duty cycleNominal power57.0W; 120.0WIP ratingup to IP68

Motor typeBrush commutated DC motor Gearbox typeSpurSizeGearbox: 104mm; DC motor:80mmNominal voltage12V/24V DC or customizedGear ratio 1:3 ~1:150No load current0.50A; 1.20ANo load speed2000rpm; 3500rpmNominal current6.0A; 10.0ANominal speed1700rpm; 3000rpmPermissible load rangeup to 30.0N.m for S1 duty cycleNominal power110.0W; 200.0WIP ratingup to IP68

Motor typeBrush commutated DC motor Gearbox typeSpurSizeGearbox: 104mm; DC motor:80mmNominal voltage12V/24V DC or customizedGear ratio 1:3 ~1:150No load current0.30A; 0.60ANo load speed2000rpm; 3500rpmNominal current3.0A; 6.50ANominal speed1700rpm; 3000rpmPermissible load rangeup to 30.0N.m for S1 duty cycleNominal power57.0W; 110.0WIP ratingup to IP68

DC SPUR GEARED MOTOR 80ZY-105JB SPECS AND FEATURE: Motor OD Size: 80MM, 90MMGearbox Size: 105JBVoltage: 12 ~ 400V DC Output Power: up to 400WRated Torque: up to 60N.mOperation Mode S1 Reduction Ratio: 5 : 1, 6.25 : 1, 10 : 1, 11.5 : 1, 31 : 1, 50 : 1
