Products

Motor type3-phase 8-pole Brushless DC motorGearbox typePlanetary DiameterGearbox: 56mm; DC motor: 57mmNominal voltage12V/24V DC or customizedGear ratio 1:3.6~1: 326No load current200mA;400mANominal current1.2A; 1.45ANo load speed2000rpm; 3000rpmNominal speed1300rpm; 2250rpmPermissible load range2N.m-20N.m for S1 duty cycleRated power10W; 25W

Motor type3-phase 8-pole Brushless DC motorGearbox typePlanetary DiameterGearbox: 56mm; DC motor: 57mmNominal voltage12V/24V DC or customizedGear ratio 1:3.6~1: 76No load current400mA; 450mANominal current2.31A; 3.47ANo load speed2000rpm; 3000rpmNominal speed1200rpm; 2000rpmPermissible load range2N.m-20N.m for S1 duty cycleRated power40W; 60W

Motor typeBrushless DC motorGearbox typePlanetaryPole8Phase3DiameterGearbox: 60mm; DC motor: 57mmNominal voltage12V/24V DC or customizedGear ratio 1:4 ~ 1:160Rated current3.47A; 4.63ANo load speed2000rpm; 3000rpmNominal speed1450rpm; 2000rpmPermissible load range0.5N.m ~ 45.0N.m for S1 duty cycleRated power60W; 80WIP ratingup to IP68

Motor type3-phase 8-pole Brushless DC motorGearbox typePlanetary DiameterGearbox: 56mm; DC motor: 57mmNominal voltage12V/24V DC or customizedGear ratio 1:3.6~1: 76No load current200mA; 300mANominal current3.47A; 4.63ANo load speed2000rpm; 3000rpmNominal speed1450rpm; 2000rpmPermissible load range2N.m-20N.m for S1 duty cycleRated power60W; 80W

Motor typeBrushless DC motorGearbox typePlanetary DiameterGearbox: 56mm; DC motor: 57mmNominal voltage24V/36V DC or customizedGear ratio 1:3.6~1: 76No load current0.80ANominal current14.0A;10.0ANo load speed4000rpmNominal speed3000rpmPermissible load range2N.m-30N.m for S1 duty cycleRated power250W

Motor typeBrushless DC motorGearbox typePlanetaryPole10Phase3DiameterGearbox: 80mm; DC motor: 80mmNominal voltage12V/24V DC or customizedGear ratio 1:5.6 ~ 1:842Rated current15.63A; 18.23ANo load speed4000rpm; 4700rpmNominal speed3000rpm; 3900rpmPermissible load range2.0N.m ~ 300.0N.m for S1 duty cycleRated power300W; 350WIP ratingup to IP68

Motor typeBrushless DC motorGearbox typePlanetaryPole10Phase3DiameterGearbox: 80mm; DC motor: 80mmNominal voltage12V/24V DC or customizedGear ratio 1:5.6 ~ 1:842Rated current10.42A; 13.02ANo load speed4000rpm; 5000rpmNominal speed3000rpm; 4000rpmPermissible load range1.0N.m ~ 300.0N.m for S1 duty cycleRated power200W; 250WIP ratingup to IP68

Motor typeBrushless DC motorGearbox typePlanetaryPole10Phase3DiameterGearbox: 80mm; DC motor: 80mmNominal voltage12V/24V DC or customizedGear ratio 1:5.6 ~ 1:842Rated current5.21A; 7.81ANo load speed4000rpm; 4900rpmNominal speed3000rpm; 4000rpmPermissible load range1.0N.m ~ 200.0N.m for S1 duty cycleRated power100W; 150WIP ratingup to IP68

Motor typeBrushless DC motorGearbox typeSpurDiameterGearbox: 60mm; DC motor: 57mmNominal voltage12V/24V DC or customizedGear ratio 1:3~1: 90No load current200mA; 400mANominal current1.2A; 1.45ANo load speed2000rpm; 3000rpmNominal speed1300rpm;2250rpmPermissible load range2N.m-5N.m for S1 duty cycleRated power10W; 25W

Motor typeBrushless DC motorGearbox typeSpur/Parallel ShaftPole8Phase3DiameterGearbox: 60mm; DC motor: 57mmNominal voltage12V/24V DC or customizedGear ratio 1:5 ~1: 200Nominal current1.2A; 1.45ANo load speed2000rpm; 3000rpmNominal speed1300rpm; 2250rpmPermissible load range2N.m ~ 15N.m for S1 duty cycleDriverExternal driverRated power10W; 25W

Motor typeBrushless DC motorGearbox typeSpurDiameterGearbox: 60mm; DC motor: 57mmNominal voltage12V/24V DC or customizedGear ratio 1:3~1:30No load current400mA;450mANominal current2.31A; 3.47ANo load speed2000rpm; 3000rpmNominal speed1200rpm; 2000rpmPermissible load range2N.m-5N.m for S1 duty cycleRated power40W; 60W
