Motor typeBrushless DC motorGearbox typeSpur/Parallel ShaftPole10Phase3DiameterGearbox: 80mm; DC motor: 80mmNominal voltage12V/24V DC or customizedGear ratio 1:5 ~1: 200Nominal current15.63A; 18.23ANo load speed4000rpm; 4700rpmNominal speed3000rpm; 3900rpmPermissible load range2N.m ~ 100N.m for S1 duty cycleDriverExternal driverRated power300W; 350W
Motor typeBrushless DC motorGearbox typeSpur/Parallel ShaftPole10Phase3DiameterGearbox: 80mm; DC motor: 80mmNominal voltage12V/24V DC or customizedGear ratio 1:5 ~1: 200Nominal current10.42A; 13.02ANo load speed4000rpm; 5000rpmNominal speed3000rpm; 4000rpmPermissible load range2N.m ~ 100N.m for S1 duty cycleDriverExternal driverRated power200W; 250W
Motor typeBrushless DC motorGearbox typeSpur/Parallel ShaftPole10Phase3DiameterGearbox: 80mm; DC motor: 80mmNominal voltage12V/24V DC or customizedGear ratio 1:5 ~1: 200Nominal current5.21A; 7.81ANo load speed4000rpm; 4900rpmNominal speed3000rpm; 4000rpmPermissible load range2N.m ~ 60N.m for S1 duty cycleDriverExternal driverRated power100W; 150W
Motor typeBrushless DC motorGearbox typeSpur/Parallel ShaftPole8Phase3DiameterGearbox: 60mm; DC motor: 57mmNominal voltage12V/24V DC or customizedGear ratio 1:5 ~1: 200Nominal current2.31A; 3.47ANo load speed2000rpm; 3000rpmNominal speed1200rpm; 2000rpmPermissible load range2N.m ~ 15N.m for S1 duty cycleDriverExternal driverRated power40W; 60W
Motor typeBrushless DC motorGearbox typeSpurPole8Phase3DiameterGearbox: 70mm; DC motor: 60mmNominal voltage12V/24V DC or customizedGear ratio 1:5 ~1: 60Nominal current3.5A; 4.63ANo load speed3600rpm; 3500rpmNominal speed3000rpmPermissible load range0.5N.m ~ 8N.m for S1 duty cycleDriverExternal driverRated power60W; 80W
2 year warranty Motor output power up to 150W Motor Types: Brushless DC Motor / Brushed DC MotorReduction Ratio: 5 : 1, 8.4 : 1, 10 : 1, 31 : 1, 50 : 1With/Without encoder
