Motor typeBrushless DC motorGearbox typePlanetaryPole10Phase3DiameterGearbox: 80mm; DC motor: 80mmNominal voltage12V/24V DC or customizedGear ratio 1:5.6 ~ 1:842Rated current15.63A; 18.23ANo load speed4000rpm; 4700rpmNominal speed3000rpm; 3900rpmPermissible load range2.0N.m ~ 300.0N.m for S1 duty cycleRated power300W; 350WIP ratingup to IP68

Motor typeBrushless DC motorGearbox typePlanetaryPole10Phase3DiameterGearbox: 80mm; DC motor: 80mmNominal voltage12V/24V DC or customizedGear ratio 1:5.6 ~ 1:842Rated current10.42A; 13.02ANo load speed4000rpm; 5000rpmNominal speed3000rpm; 4000rpmPermissible load range1.0N.m ~ 300.0N.m for S1 duty cycleRated power200W; 250WIP ratingup to IP68

Motor typeBrushless DC motorGearbox typePlanetaryPole10Phase3DiameterGearbox: 80mm; DC motor: 80mmNominal voltage12V/24V DC or customizedGear ratio 1:5.6 ~ 1:842Rated current5.21A; 7.81ANo load speed4000rpm; 4900rpmNominal speed3000rpm; 4000rpmPermissible load range1.0N.m ~ 200.0N.m for S1 duty cycleRated power100W; 150WIP ratingup to IP68

Motor typeBrushless DC motorGearbox typeSpurDiameterGearbox: 60mm; DC motor: 57mmNominal voltage12V/24V DC or customizedGear ratio 1:3~1: 90No load current200mA; 400mANominal current1.2A; 1.45ANo load speed2000rpm; 3000rpmNominal speed1300rpm;2250rpmPermissible load range2N.m-5N.m for S1 duty cycleRated power10W; 25W

Motor typeBrushless DC motorGearbox typeSpur/Parallel ShaftPole8Phase3DiameterGearbox: 60mm; DC motor: 57mmNominal voltage12V/24V DC or customizedGear ratio 1:5 ~1: 200Nominal current1.2A; 1.45ANo load speed2000rpm; 3000rpmNominal speed1300rpm; 2250rpmPermissible load range2N.m ~ 15N.m for S1 duty cycleDriverExternal driverRated power10W; 25W

Motor typeBrushless DC motorGearbox typeSpurDiameterGearbox: 60mm; DC motor: 57mmNominal voltage12V/24V DC or customizedGear ratio 1:3~1:30No load current400mA;450mANominal current2.31A; 3.47ANo load speed2000rpm; 3000rpmNominal speed1200rpm; 2000rpmPermissible load range2N.m-5N.m for S1 duty cycleRated power40W; 60W

45ZY12-70120 DC PARALLEL SHAFT GEAR MOTOR TYPICAL SPECS.: · Voltage 12V DC· Rated Current 2.15A· No-load Speed 4RPM· Rated Speed 2.8RPM· Rated Torque 10N.m· Gearbox Ratio 1010/1 ( Other Ratios Available Upon Request )

110ZYT 4-POLE PERMANENT MAGNET DC MOTOR TYPICAL SPECS.· Voltage: 24V DC· Rated Output Power: 700W· Rated Speed: 3000RPM· Without Gearbox· Customized shaft & front cover (NEMA 48C, NEMA 56C,  IEC61/71/80 B5/B14, NEMA 143TC/145TC, TENV, TEFC) available upon request

DC RIGHT ANGLE GEARMOTOR 90ZYT/140WJ TYPICAL SPECS.:·  Voltage 12V DC·  Current approx. 25A·  Rated Torque 35N.m·  Rated Speed 34RPM·  Gearbox Ratio 134 : 1 / Two-stage

Motor typeBrushless DC motorGearbox typeSpur/Parallel ShaftPole8Phase3DiameterGearbox: 60mm; DC motor: 57mmNominal voltage12V/24V DC or customizedGear ratio 1:5 ~1: 200Nominal current2.31A; 3.47ANo load speed2000rpm; 3000rpmNominal speed1200rpm; 2000rpmPermissible load range2N.m ~ 15N.m for S1 duty cycleDriverExternal driverRated power40W; 60W

Motor typeBrushless DC motorGearbox typeSpurPole8Phase3DiameterGearbox: 70mm; DC motor: 60mmNominal voltage12V/24V DC or customizedGear ratio 1:5 ~1: 60Nominal current3.5A; 4.63ANo load speed3600rpm; 3500rpmNominal speed3000rpmPermissible load range0.5N.m ~ 8N.m for S1 duty cycleDriverExternal driverRated power60W; 80W
